Cipherlab RK25 Rugged Mobile Computer

When it comes to environments which require a big volume of data collection and entry, such as retailing, light warehousing and field mobility, CipherLab RK25 mobile computer effortlessly combines the benefits of touch computers with handheld mobility into one reliable device.

  • OS: Android 7.0 / 9.0 / 11.0 with GMS
  • Reads 1D/2D barcodes, NFC cards, and RFID tags.
  • Supports a 2D imager with 4 m long reading range.
  • Easily add UHF RFID reading capability by attaching RK25 onto RK25 UHF RFID reader.
  • 25-key keypad with 2 function keys and 28-key keypad with 4 function keys
  • Crafted battery design integrated with a latch for easy replacement.

Download Brochure

Send Enquiry
Category

Crafted with operation-friendly designs, up-to-date features, powerful wireless options and versatile data capture functionality, the CipherLab RK25 mobile computer creates a perfect blend of new age features and classic usability to maximize your enterprise’s usability.

Big Display and Friendly Operation Design
With large and easy to use buttons, RK25 is made to best suit your specific preferences. Its 4”display with multi-touch panel has auto-adjustable backlight and sunlight visibility to ensure readability in all environments. Its 10 and 70 degree reading angles make on-screen data checking simple by allowing users to read barcodes without laying the RK25 flat. Moreover, its compact 292g, curved grip design reduces extended usage fatigue while delivering comfortable one-hand operation.

Trustworthy Wi-Fi and Real-time Communication
The RK25’s Wi-Fi transmission (IEEE802.11 a/b/g/n/ac) of dual band and fast roaming is the true definition of dependability in data-intensive environments such as warehouses. Furthermore, RK25’s 4G/LTE can facilitate large file transmissions with high speed such as video streaming and remote access to back-end systems. Drive time is reduced with built-in GPS, GLONASS, Beidou and AGPS, providing the most accurate navigation. Communication among workers is kept at the most efficient level with instant voice connection, VoLTE with high definition voice or VoIP (PTT) with noise cancellation.

Durability to Support Harsh Environments
The CipherLab RK25’s IP65 rating, 1.5 m drop resistance and 300 tumbles at 0.5 m help support continuous work in rainy and dusty environment while fully protected against accidental drops. You don’t have to worry about scratching the screen with the help of Corning Gorilla Glass. The keypad’s numbers and letters have been inked with technology that won’t fade with heavy usage. Moreover, it passed the durability test of one million keystrokes. On top of that, the 4000 mAh hot-swappable battery keeps the durable productivity going for long shifts in any environment.

Industry Use

  • Transportation
  • Distribution Centre
  • Manufacturing
  • Cold Storage
  • Direct Store Delivery
  • Field Mobility
  • Retail

Specifications

OS

  • Android 7.0 with GMS (Upgradeable to Android 9.0 with GMS)
  • Android 9.0 with GMS (Upgradeable to Android 11.0 with GMS)
  • Android 11.0 with GMS

CPU

  • Quad-core 1.4 GHz Cortex A53

Memory

  • 2GB RAM / 16GB Flash
  • 3GB RAM/ 32GB Flash1

Expansion

  • Micro SD card slot with SDHC support (up to 32GB)

SIM / SAM

  • 1 SIM slot and 1 optional SIM/SAM slot

Operating Power

  • Replaceable and rechargeable 3.8V, 4000 mAh Li-Polymer battery

Working Hours

  • Minimum 8 hours (2D imager)

Wireless Communication

  • WWAN3: GSM: Quad Band (850/900/1800/1900Mhz)
  • TD-SCDMA: Band34, Band39
  • WCDMA: Band1, Band2, Band5, Band8,
  • TDD-LTE: Band38, Band39, Band40, Band41
  • FDD-LTE: Band1,Band2, Band3, Band5, Band7, Band8, Band20
  • WLAN: IEEE 802.11 a/b/g/n/ac/e/d/h/i/r/k/v/w dual band
  • WPAN: Bluetooth® Class II, V4.0/V4.1/V4.2 BLE, V2.1 with Enhanced Data Rate (EDR)
  • GPS4: GPS, Galileo, GLONASS, BeiDou, AGPS

Barcode Scanning

  • 2D imager / Mid-Range 2D imager

RFID (Optional)

  • HF RFID 13.56 MHz frequency which supports ISO14443 TYPE A,B, and ISO15693
  • Support NFC (Peer-to-Peer, Card Reader, Card Emulation)

Camera (Optional)

  • Autofocus 8 megapixels with LED flash

Display

  • 4” WVGA 480 (W) x 800 (H), Corning Gorilla Glass, TN LCD

Size

  • 168 x 73.8 x 26 mm

Weight

  • 292 g (2D imager with battery)

Impact Resistance

  • Standard: 1.5 m (5 ft.) multiple drops onto concrete
  • With rubber boot: 1.8 m (6 ft.) MIL-STD-810G IP65 / 300 tumbles at 0.5 m
